Top level Android 9.0 X3 TV Box 4K Amlogic S905X3 Quad core dual wifi smart OTT box

Model No.:

X3

Model Name:

S905X3 Smart TV Box

Hardware

CPU

S905X3 64-bit quad core ARM® Cortex™ A55 CPU

GPU

ARM G31™ MP2 GPU processor OpenGL ES 3.2 Vulkan 1.0 and OpenCL 2.0

RAM

2/4GB

ROM

16/32/64GB

WiFi

2.4/5.8G 802.11b/g/n/ac +BT 5.0

Main Features

OS

Android 9.0

Support Decoder format

HW UHD 4K H.265 60fps 10-bit video decoder & low latency
1080p H.265/H.264 60fps encoder VP9 Profile-2 up to 4Kx2K@60fps
H.265 HEVC [email protected] up to 4Kx2K@60fps
AVS2-P2 Profile up to 4Kx2K@60fps
H.264 AVC [email protected] up to 4Kx2K@30fps
H.264 MVC up to 1080P@60fps
MPEG-4 ASP@L5 up to 1080P@60fp (ISO-14496)
WMV/VC-1 SP/MP/AP up to 1080P@60fps
AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps
MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
RealVideo 8/9/10 up to 1080P@60fps
Multiple language and multiple format sub-title video support
MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)
Supports JPEG thumbnail, scaling, rotation and transition effects
Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats

Support Media format

Avi/Ts/MP4/Mkv/Mov/ISO/RM/MOV/Flv/Dat/mpg/mpeg

Support Music format

MP3/WMA/AAC/WAV/OGG/DDP/HD/FLAC/APE/AC3/DTS etc.

Support Photo format

HD JPEG/BMP/GIF/PNG/TIFF

HDR

HDR10 and HLG

HDD file system

FAT16/FAT32/NTFS

Support Subtitle

SRT/SMI/SUB/SSA/IDX+USB

High Definition video output

4K (3840x2160 pixel )

OSD type of languages

English/French/German/Spanish/Italian/ etc multilateral languages

Mouse/ Keyboard

Support mouse and keyboard via USB;Support 2.4GHz wireless mouse and keyboard via 2.4GHz USB dongle

LAN

Standard 10/100M

HDMI

Built-in HDMI 2.1 transmitter including both controller and PHY with CEC, Dynamic HDR

Remote Control

IR remote control

AV

Support

Optical

Support

USB host

1*High speed USB 3.0 1*USB 2.0

Card reader

1*TF Card Upto 128GB Support SDHC/SDXC

LED digital tube

Support

DC

∮4.0*1.7 mm DC 5V@2A

Appliactions

Kodi

Kodi 18

Other feature

Free Internet searching,thousands of android applications,many kinds of games,etc.

Accessories

Power adaptor,HDMI cable,user manual ,remote
