| EB-FU01 |
CPU
(Processor) | Tiger Lake | i3-1115G4 （2core/4threads 3.0GHz-4.1Ghz 6MB Cache）
i5-1135G7 (4core/8threads 2.4GHz-4.8Ghz 8MB Cache）
i7-1165G7 (4core/8threads 2.8GHz-4.7Ghz 12MB Cache) |
| Intergated GPU | Intel Graphic | i3-1115G4 (Intel® UHD Graphics 1.25GHz)
i5-1135G7 (Intel® Iris® Xe Graphics 1.30GHz)
i7-1165G7 (Intel® Iris® Xe Graphics 1.30GHz) |
| BIOS | Other function
for optioanl | Auto Power On |
| Real-time Clock, timing boot |
| Wake-up On LAN |
| Memory | Memory Type | 2* DDR4-3200Mhz SO-DIMM,Max 64GB (Memory not included) |
| SSD | M.2 SSD | 1 * M.2(SATA III / Nvme / intel Optane) 2280 SSD (SSD not included) |
Wireless
Configuration | M.2 | Wifi5: Support 2.4&5.0G WiFi Card included ,
Wifi6: Supported (Optional) WiFi Card not included |
| Bluetooth | Bluetooth 4.2 Combo in WiFi Moduel （Bluetooth 5.1 for optional） |
| I/O Interface | USB | 2 * USB 2.0, 4 * USB 3.0 |
| HDMI | 1 * HDMI 2.0. Support 4K*60Hz output. Max to 4096 x 2304 @60Hz |
| DP | 1 * DP 1.4. Support t 4K*60Hz output. Max to 7680x4320 @60Hz |
| LAN | 1 * RJ45 100M/1000M |
| Type-c | support eGPU（Video output, support 8K; PD power supply; The data transfer） |
| Audio | 1 * 3.5mm Audio Jack (MIC/SPK Combo) |
| Other Hardware | Switch | 1 x Power On/Off Switch |
| Fan | No fan |
| LED | 1 x LED |
| Operation System | Windows | Win8.1/Win10/Win11 |
| Linux | Ubuntu |
| Power | Power Type | DC-In |
| Power Adapter | 19V/65W(∮5.5mm*2.5mm power connector) |
| Package Specifications | Material | Aluminum Alloy |
| Color | Iron Gray |
| Products Dimension | 190*128*64mm 1.5kg/pcs |
